4. Push the new bulb into the bulb socket assembly.
5. Insert the bulb assembly into the headlamp housing.
6. Rotate the bulb assembly clockwise until seated.
7. Reverse the steps to reinstall the lamp assemblies.
Fog Lamps
To replace a fog lamp bulb, do the following:
1. Reach through opening in lower front fascia to gain
access to the fog lamp bulb electrical connector.
2. Disconnect bulb electrical connector by lifting the
locking tab and pull it rearward to remove the
connector.
3. Rotate the bulb socket counterclockwise to
remove it.
4. Remove the bulb and replace it with the
appropriate bulb.
5-51
