Capacities and Specifications
Application
Capacities
English Metric
Air Conditioning Refrigerant R134a
2.2L L4 (L61) 1.5 lbs 0.68 kg
3.5L V6 (L66) 1.8 lbs 0.79 kg
Cooling System
2.2L L4 (L61) 7.4 quarts 7.0 L
3.5L V6 (L66) 9.7 quarts 9.2 L
Engine Oil with Filter
2.2L L4 (L61) 5.0 quarts 4.7 L
3.5L V6 (L66) 4.5 quarts 4.3 L
Fuel Tank 16.5 gallons 62.4 L
Transaxle
Five-SpeedAutomatic (RPO MJ7) 4.5 quarts 4.3 L
Five-Speed Automatic Red Line Model (RPO MJ8) 4.1 quarts 3.9 L
Four-Speed Automatic (RPO MN5) 7.0 quarts 6.6 L
Five-Speed Manual (RPO MG3) 1.8 quarts 1.7 L
VTi Variable (RPO M75 and M16) 7.0 quarts 6.6 L
Wheel Nut Torque 92 ft lb 125 Y
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.
5-99
