Engine Air Cleaner/Filter
See Engine Compartment Overview on page 5-12 for
the location of the engine air cleaner/filter.
When to Inspect the Engine Air
Cleaner/Filter
Inspect the air cleaner/filter at the Maintenance II
intervals and replace it at the first oil change after
each 50,000 mile (80 000 km) interval. See Scheduled
Maintenance on page 6-3 for more information.
If you are driving in dusty/dirty conditions, inspect
the filter at each engine oil change.
How to Inspect the Engine Air
Cleaner/Filter
To inspect the air cleaner/filter remove the filter from
the vehicle and lightly shake the filter to release
loose dust and dirt. If the filter remains caked with
dirt, a new filter is required.
To inspect or replace the engine air cleaner/filter, do the
following:
1. Unscrew the clamp on
the air duct hose.
2. Disconnect the hose.
3. Unscrew the four bolts on the side of the air cleaner
assembly.
5-20
