Windshield Wiper Blade
Replacement
Front Windshield Wiper
Windshield wiper blades should be
inspected for wear or cracking.
See “Maintenance Replacement
Parts” in the Limited Warranty,
Maintenance and owner Assistance
Information manual for the proper
type and length.
Raise the wiper arm, tilt the wiper
blade at a 90° angle to the
wiper arm, and remove to the side.
1. Turn the ignition off.
2. With the key in the ignition and
key in the LOCK position, press
the wiper lever down. Release
the wiper lever when the wipers
are in the vertical position.
3. Raise the wiper arm away from
the windshield.
4. Turn the wiper blade at a 90°
angle to the wiper arm and
remove the blade to the side.
5. Install the new wiper blade.
6. Lower the wiper arm on to the
windshield.
Rear Windshield Wiper
1. Lift the wiper arm straight up.
2. Push the wiper blade straight out
of the wiper arm to remove.
3. Install the new wiper blade.
Vehicle Service and Care 9-21
