A. Engine Air Cleaner/Filter. See Engine Air
Cleaner/Filter on page 264.
B. Electric Engine Cooling Fan (Out of View). See
Cooling System on page 270.
C. Engine Oil Dipstick (Out of View). See “Checking
Engine Oil” under Engine Oil on page 260.
D. Engine Oil Fill Cap (Out of View). See “When to Add
Engine Oil” under Engine Oil on page 260.
E. Brake Fluid Reservoir. See Brakes on page 277.
F. Engine Coolant Surge Tank. See “Checking Coolant”
under Engine Coolant on page 266.
G. Remote Positive (+) Terminal. See Jump Starting on
page 280
H. Underhood Fuse Block. See Underhood Fuse Block
on page 346.
I. Battery. See Battery on page 279.
J. Windshield Washer Fluid Reservoir. See “Adding
Washer Fluid” under Windshield Washer Fluid
on page 276.
When you open the hood on the 3.5L V6 engine (3.6L V6 similar), you will see the following:
257
