Step 10
401291www.sauder.com/services
Pae 15
å
Insert the LARGE DRAWER SIDES (D22 and D23)
at an angle into the slot at each end of the LARGE
DRAWER FRONT (G2).
å
Slide the DRAWER BOTTOM (D981) into the grooves in
the LARGE DRAWER SIDES (D22 and D23) and LARGE
DRAWER FRONT (G2).
å
Fasten the DRAWER BRACE (M64) to the LARGE
DRAWER FRONT (G2). Tighten one HIDDEN CAM.
å
Fasten the LARGE DRAWER BACK (D175) to the LARGE
DRAWER SIDES (D22 and D23) and DRAWER BRACE (M64).
Use five BLACK 1-9/16" FLAT HEAD SCREWS. (30S). Repeat
this step for the other large drawers.
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Surface with
HIDDEN CAM
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
VIEW THE T-LOCK BOX VIDEO
Unfi nished
surface
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
G2
D981
D22
D23
D175
M64
G2
D22
D23
G2
M64
D22
D23
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(15 used in this step)
30S
