Step 11
401291 www.sauder.com/servicesPae 16
Z
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
RR
1
3
2
Unfi nished surface
Push down
å
Pull the DRAWER FRONT BRACKETS (Z) apart and slide them into
the rooves in the SMALL DRAWER SIDES (D245 and D271). You
may need to ently tap them in with a hammer.
å
NOTE: The DRAWER FRONT BRACKETS are marked "RH" and "LH"
for easy identifi cation.
å
Fasten the SMALL DRAWER FRONT (L2) to the DRAWER FRONT
BRACKETS (Z). Use four BLACK 9/16" LARGE HEAD SCREWS (RR).
å
Slide the DRAWER BOTTOM (D981) into the rooves
in the SMALL DRAWER SIDES (D245 and D271) and
SMALL DRAWER FRONT (L2).
å
Fasten the DRAWER BRACE (M64) to the SMALL DRAWER FRONT (L2). Tihten one HIDDEN CAM.
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of
your hand, tap
the DRAWER
BOTTOM down
into the roove.
Arrow
Maximum
210 derees
Minimum
190 derees
Surface with
HIDDEN CAM
L2
D271
M64
D245
D981
L2
D271
D245
L2
