Sauder 402159 - Part Identification; Assembly Tools Required

Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4
5-24
25-28
29-32
33-34
35
A TOP (1)
B MODESTY PANEL (1)
C LEFT END (1)
D LEFT UPRIGHT (1)
E RIGHT UPRIGHT (1)
F RIGHT END (1)
G BASE MOLDING (4)
H LARGE DRAWER LEFT SIDE (3)
I LARGE DRAWER RIGHT SIDE (3)
J LARGE DRAWER BOX FRONT (3)
K LARGE DRAWER BACK (3)
L BRACE (4)
M KEYBOARD FRONT (1)
N BACK (2)
O DRAWER FRONT (8)
P SMALL DRAWER LEFT SIDE (2)
Q SMALL DRAWER RIGHT SIDE (2)
R SMALL DRAWER BACK (2)
S DRAWER BOTTOM (5)
T SIDE MOLDING (4)
U KEYBOARD SHELF (1)
V LEFT KEYBOARD SIDE (1)
W RIGHT KEYBOARD SIDE (1)
X KEYBOARD BACK (1)
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
Page 2 www.sauder.com 402159
