Sauder 408761 - Page 8

Step 4
å
Finish drilling the six holes shown in the bottom surface of
the TOP (F) using a 1/4" or 6.5mm drill bit.
å
Next, fasten the TOP (F) to the UPRIGHTS (D and E). Use
six BLACK 1-7/8" FLAT HEAD SCREWS (LL).
408761 www.sauder.com/servicesPage 8
F
D
D
E
Unfi nished surface
Long rounded edge
BLACK 1-7/8" FLAT HEAD SCREW
(6 used in this step)
LL
Finish drilling the holes from
the bottom surface. Use a
1/4" or 6.5mm drill bit. Then,
use six BLACK 1-7/8" FLAT
HEAD SCREWS (LL).
