Fasten the UPRIGHTS (C and D) to the SHELF (H).
Tighten four HIDDEN CAMS.
Step 7
419119www.sauder.com/services
Page 11
Arrow
Minimum
190 degrees
Maximum
210 degrees
H
D
C
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Notched edge
