å
Fasten the RIGHT END (A) to the TOP (F), BOTTOM (G),
and SHELF (H). Tighten six HIDDEN CAMS.
Step 10
419119 www.sauder.com/servicesPage 14
Arrow
Minimum
190 degrees
Maximum
210 degrees
G
H
F
A
Long edge with
HIDDEN CAMS
