Fasten the LEFT END (B) to the TOP (F). Tighten two
HIDDEN CAMS.
å
Insert two METAL PINS (1R) into the SMALL UPRIGHT (E).
å
Insert the METAL PINS (1R) in the end of the SMALL
UPRIGHT (E) into the holes in the TOP (F).
Step 5
419119www.sauder.com/services
Page 9
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
B
F
E
1R
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
R
Surface with holes
Surface with
HIDDEN CAMS
Long edge with
HIDDEN CAMS
Finished edge
