Sauder 419954 - Step 23

Step 23
419954www.sauder.com/services
Pae 27
VIEW THE T-LOCK BOX VIDEO
å
NOTE: The SMALL drawers will only use two SCREWS per drawer. Refer to the diaram.
å
Fasten the SMALL DRAWER BACK (D109) to the SMALL DRAWER SIDES (D24 and D25). Use two BLACK 1-9/16" FLAT
HEAD SCREWS (30S).
å
NOTE: Be sure the SMALL DRAWER BOTTOM (D716) inserts into the roove of the SMALL DRAWER BACK (D109).
å
Repeat this step for the other SMALL drawers.
12
3
å
Insert the SMALL DRAWER SIDES (D24 and D25)
at an anle into the slot at each end of the SMALL
DRAWER FRONT (V).
å
Slide the SMALL DRAWER BOTTOM (D716) into the
rooves in the SMALL DRAWER SIDES (D24 and D25)
and SMALL DRAWER FRONT (V).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
30S
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(8 used in this step)
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
D24
D25
D716
D716
D24
D25
D109
D25
V
V
Unfi nished
surface
D24
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
NOTE: Do not use this hole
in the SMALL drawers. This
hole will be used in Step 25.
With the palm of your hand,
tap the DRAWER BOTTOM
down into the roove.
