Insert a SLIDE CAM (10A) into the LARGE DRAWER SIDES (D28 and D29).
å
Fasten two WIDE EXTENSION SLIDES (Z) to the LARGE DRAWER SIDES (D28
and D29). Use four GOLD 5/16" FLAT HEAD SCREWS (3S) throuh
holes #1 and #4.
å
NOTE: The screw head in the CAM must be visible throuh the slotted hole in
the SLIDE.
å
Repeat this step for the other LARGE drawer.
D28
D29
Open end
Open end
1
2
3
1
2
3
Z
Z
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
10A
4
4
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
(4 screws per drawer)
