Sauder 420203 - Page 16

Step 12
å
Insert two SMALL HIDDEN CAMS (6) into the LARGE BACK (J).
å
Fasten the CENTER END (F) the LARGE BACK (J). Tighten two
HIDDEN CAMS.
å
Fasten the CENTER LEG (C) to the SHORT BRACES (P). Use
two BLACK 1/2" MACHINE SCREWS (20).
Page 16 www.sauder.com 420203
3
21
6
The arrow must
point toward the
edge of the board.
J
P
6
BLACK 1/2" MACHINE SCREW
(2 used for the SHORT BRACES)
20
P
C
F
