Sauder 420203 - Page 21

å
Fasten the LONG BRACES (O) to the LEGS (B and C). Use four
BLACK 1/2" PAN HEAD SCREWS (18).
å
NOTE: Start all the SCREWS a few turns before tightening them.
å
Fasten the LONG BRACES (O) together. Use the BLACK 5/16"
MACHINE SCREW (21) and NUT (11) in the center holes in the
LONG BRACES.
å
NOTE: If the center holes in the LONG BRACES (O) do not line
up, loosen the SCREWS in the LEGS and then retighten once
the LONG BRACES are fastened together.
å
NOTE: Tighten the NUT using the TOOL (12).
Step 17
Page 21www.sauder.com420203
BLACK 1/2" PAN HEAD SCREW
(4 used in this step)
18
C
B
O
12
BLACK 5/16" MACHINE SCREW
(1 used in this step)
21
21
11
