Sauder 420203 - Page 25

å
Turn four CAM SCREWS (7) into the DRAWER FRONT (Z).
å
Insert four SMALL HIDDEN CAMS (6) into the DRAWER
SIDES (U and V).
å
Insert two WOOD DOWELS (8) into the DRAWER BRACE (Y).
å
Fasten the DRAWER FRONT (Z) to the DRAWER SIDES (U
and V). Tighten four HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWELS insert into the holes in
the DRAWER FRONT.
å
Fasten a PULL (10) to the DRAWER FRONT (Z). Use
two BLACK 1/2" MACHINE SCREWS (17).
Step 21
Page 25www.sauder.com420203
3
21
6
The arrow must
point toward the
edge of the board.
7
7
Z
Z
V
U
X
8
BLACK 1/2" MACHINE SCREW
(2 used for the PULL)
17
6
6
Y
10
Be sure the DRAWER
BOTTOM (X) inserts
into the groove in the
DRAWER FRONT (Z).
