Sauder 423033 - Assembly Tools Required; Part Identification Guide

Table of Contents Assembly Tools Required
2-3
4
5-18
19-21
22-24
25-26
27
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
423033 www.sauder.com/servicesPage 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
A2 RIGHT END (1)
B2 LEFT END (1)
C LOWER RIGHT END (1)
D LOWER LEFT END (1)
E2 TOP (1)
F BOTTOM (1)
G2 SHELF (1)
H2 LARGE BACK (1)
I BACK (1)
J ADJUSTABLE SHELF (3)
K END MOLDING (2)
M25 TOP MOLDING (1)
M48 BASE (1)
N SHELF MOLDING (3)
O SKIRT (1)
P LOWER END MOLDING (2)
Skip the power trip.
This time.
Tape Measure
