Sauder 426930 - Step 9: Assemble Front Skirt Components; Insert Dowels into End Panels; Attach Metal Brackets to Front Skirt; Connect Front Skirt to Bottom and End Panels

Step 9
å
Carefully turn your unit onto its back edges.
å
Insert two WOOD DOWELS (1) into the ENDS (A and B)
as shown.
å
Fasten five METAL BRACKETS (6) to the FRONT
SKIRT (M). Use ten 1/2" FLAT HEAD SCREWS (13).
å
Fasten the FRONT SKIRT (M) to the BOTTOM (G) and
ENDS (A and B). Use ten 1/2" FLAT HEAD SCREWS (13)
through the METAL BRACKET and into the BOTTOM
and ENDS.
å
NOTE: Be sure the WOOD DOWEL in the ENDS insert
into the holes in the FRONT SKIRT.
B
A
M
G
1
1
M
6
6
1/2" FLAT HEAD SCREW
(20 used in this step)
13
Surface without holes
13
Page 13www.sauder.com/service426930
6
