Sauder 429430 - Step 5: Shelf Installation and Decorative Appliques

Step
å
Finish fastening the BOTTOM (E) to the SKIRT (L). Use
two 1-3/8" FLAT HEAD SCREWS (13).
å
Fasten the SHELF (F) to the UPRIGHT (C). Use two 1-3/8"
FLAT HEAD SCREWS (13).
å
Finish fastening the SHELF (F) to the UPRIGHT (C). Use
two 1/2" PAN HEAD SCREWS (18) through the METAL
BRACKETS on the UPRIGHT and into the SHELF.
å
Then, peel four APPLIQUES (7) from the applique card
and stick them over the heads of the SCREWS (13).
Step 5
E
C
F
Peel the APPLIQUES
from the applique card.
7
L
7
The molding on the
SHELF should be here.
1/2" PAN HEAD SCREW
(2 used in this step)
18
7
1-3/8" FLAT HEAD SCREW
(4 used in this step)
13
Page 9www.sauder.com429430 / 168-0094-8
