Sauder 430083 - Page 7

å
Fasten four ANGLE BRACKETS (4) to the BASES (G).
Use four 1/2" PAN HEAD SCREWS (14) as shown to
the right.
å
NOTE: Be sure the edges of the ANGLE BRACKETS
are even with the edges of the BASES.
å
Insert six WOOD DOWELS (1) into the BOTTOM (E).
å
Fasten the ANGLE BRACKETS on the BASES (G) to
the BOTTOM (E). Use four 1/2" PAN
HEAD SCREWS (14).
å
NOTE: Be sure the WOOD DOWELS in the BOTTOM
insert into the BASES.
Step 2
E
G
G
G
G
1
1
4
1/2" PAN HEAD SCREW
(8 used for the ANGLE BRACKETS)
14
Page 7www.sauder.com/service430083
