Step 10
å
Fasten four CARD HOLDERS (35M) to each SHELF
MOLDING (Q). Use sixteen SILVER 3/8"
MACHINE SCREWS (97S).
å
Fasten the SHELF MOLDINGS (Q)
to the SHELVES (H). Tighten
eight HIDDEN CAMS.
414726 www.sauder.com/servicesPage 14
H
H
H
H
Q
Q
Q
Q
35M
Arrow
Minimum
190 degrees
Maximum
210 degrees
SILVER 3/8" MACHINE SCREW
(16 used for the CARD HOLDERS)
97S
(8 used)
Unfi nished surface
Unfi nished surface
Card slot
To Next Page
