Sauder Bookcase 414726 - Assembly Tools Required; Part Identification

Table of Contents Assembly Tools Required
2-3
4
5-16
17-18
19-20
21-22
23
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
414726 www.sauder.com/servicesPage 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D UPPER UPRIGHT (2)
E LOWER UPRIGHT (2)
F TOP (1)
G BOTTOM (2)
H SHELF (4)
I BACK (2)
J FRONT SKIRT (1)
K SIDE SKIRT (2)
L SIDE RAIL (2)
M BACK RAIL (1)
N FRONT MOLDING (1)
O RIGHT MOLDING (1)
P LEFT MOLDING (1)
Q SHELF MOLDING (2)
