Step 1
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å
Assemble your unit on a carpeted fl oor or on the empty
carton to avoid scratching your unit or the fl oor.
å
Push thirty-eight HIDDEN CAMS (1F) into the ENDS (A
and B), UPRIGHT (C), BOTTOMS (G), and SHELVES (H).
Then, insert the metal end of a CAM DOWEL (2F) into
each HIDDEN CAM.
414726www.sauder.com/services
Page 5
A
B
C
G
H
G
H
H
H
Arrow
1F
2F
(38 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1711
to watch a video on how to assemble your unit.
