Step 5
Page 10
A
å
Turn two BLACK 9/16" FLAT HEAD SCREWS (32S) into
the RIGHT END (A) until the shoulders of the SCREWS
rest on the surface of the END.
å
NOTE: Do not overtighten the SCREWS.
å
Slide the END MOLDING (M75) onto the END (A). Line
up the groove in the MOLDING over the heads of the
SCREWS in the END.
å
NOTE: The MOLDING should be even on both edges of
the END.
å
NOTE: If the MOLDING comes up o of the SCREWS,
remove it and slide it on again.
BLACK 9/16" FLAT HEAD SCREW
(2 used in this step)
32S
Shoulder
Apply pressure with your hands
as you guide the MOLDING over
the SCREWS and onto the END.
Surface without
HIDDEN CAMS
M75
