Step 21
Page 28
D48
D48
D716
D49
D49
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT groove.
å
Pull the FILE DRAWER FRONT BRACKETS (10G) apart and slide
them into the grooves in the FILE DRAWER SIDES (D48 and D49).
å
NOTE: The FILE DRAWER FRONT BRACKETS are marked "RH"
and "LH" for easy identifi cation.
å
Fasten the FILE DRAWER FRONT (N) to the FILE DRAWER
FRONT BRACKETS (10G). Use four BROWN 9/16" LARGE
HEAD SCREWS (40S).
å
Slide the SMALL DRAWER BOTTOM (D716) into the grooves in
the FILE DRAWER SIDES (D48 and D49) and FILE
DRAWER FRONT (N).
Tap down with your
screwdriver and hammer.
D49
10G
With the palm of your hand,
tap the DRAWER BOTTOM
down into the groove.
N
Unfi nished surface
N
BROWN 9/16" LARGE HEAD SCREW
(4 used for the FRONT BRACKETS)
40S
Groove
To Next Page
