Page 27
Step 20
å
Fasten a DRAWER RIGHT (40CC) and a DRAWER LEFT (40CD)
to the PENCIL DRAWER SIDES (D113). Use four GOLD 5/16" FLAT
HEAD SCREWS (3S) through holes #2 and #4.
å
Fasten two KNOB SETS (52K) to the PENCIL DRAWER FRONT (R3).
Use two SILVER 1-1/2" MACHINE SCREWS (95S).
R3
1
2
3
4
1
2
3
4
D113
Roller end
Roller end
D113
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
SILVER 1-1/2" MACHINE SCREW
(2 used for the KNOB SETS)
95S
52K
To Next Page
