Page 31
Step 24
å
Fasten a DRAWER RIGHT (40CC) to the FILE RIGHT DRAWER
SIDE (D48) and a DRAWER LEFT (40CD) to the FILE LEFT
DRAWER SIDE (D49). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) through holes #2 and #4.
å
Repeat this step for the other drawer.
1
2
3
4
1
2
3
4
D48
D49
Roller end
Roller end
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
To Next Page
