å
Turn the ENDS (A and B) over.
å
Fasten the FRONT LEGS (G and H) to the ENDS (A and B).
Tihten six HIDDEN CAMS.
Step 5
415520 www.sauder.com/servicesPae 10
A
B
G
H
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
12
End with HIDDEN
CAMS and CAM
DOWELS
End with HIDDEN
CAMS and CAM
DOWELS
Anled ede
Top edes
should be even.
Top edes
should be even.
Anled ede
