Fasten the LEFT END (B) and UPRIGHT (C) to the TOP (D).
Tihten four HIDDEN CAMS.
Step 7
415520 www.sauder.com/servicesPae 12
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Surface with holes
Surface
with
HIDDEN
CAMS
Surface
with
HIDDEN
CAMS
Start Tihten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
B
C
D
Finished ede
Curved ede
