Fasten the BOTTOM (E) to the LEFT END (B). Tihten two
HIDDEN CAMS.
å
Fasten the BOTTOM (E) to the UPRIGHT (C) Use two BLACK
1-7/8" FLAT HEAD SCREWS (2S).
å
Slide the SKIRT (J) onto the notched ede of the BOTTOM (E).
*U.S. Patent No. 5,499,886
Step 8
415520www.sauder.com/services
Pae 13
E
J
Arrow
Minimum
190 derees
Maximum
210 derees
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
Notched ede
Surface with HIDDEN CAMS
