å
Fasten the RIGHT END (A) to the TOP (D) and
BOTTOM (E). Tihten four HIDDEN CAMS.
Step 9
415520 www.sauder.com/servicesPae 14
D
E
A
Surface without
HIDDEN CAMS
Arrow
Minimum
190 derees
Maximum
210 derees
