Sauder Carson Forge Armoire - Page 20

Step 15
å
Refer to the enlared diaram to identify the parts on
the HINGES.
å
The DOORS may need some adjustments. Follow the text
below to make needed adjustments.
å
DOOR ADJUSTMENTS:
To adjust the DOORS from side to side (horizontal), turn the
adjustin screw in or out.
å
To adjust the DOORS up and down (vertical), loosen both
vertical adjustment screws. Move the DOORS up or down to the
desired location. Tihten the screws after makin adjustments.
å
To adjust the DOORS in or out (depth), loosen the mountin
screw one turn and move the DOORS in or out, as needed.
Tihten the mountin screw after makin adjustments.
Adjustin screw (horizontal)
Mountin screw (depth)
(vertical adjustment)
415107 www.sauder.com/servicesPae 20
