Sauder Harbor View 403793 - Step 26: Assemble Drawer Sides and Bottom

Step 27
403793www.sauder.com/services
Pae 31
VIEW THE T-LOCK BOX VIDEO
å
Fasten the DRAWER BACK (D78) to the DRAWER SIDES (D28
and D29). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S).
å
NOTE: Be sure the DRAWER BOTTOM (D707) inserts into the
roove of the DRAWER BACK (D78).
å
Repeat this step for the small drawers usin parts U, D24, D25,
D109, and D716.
12
3
å
Insert the DRAWER SIDES (D28 and D29) at an anle
into the slot at each end of the DRAWER FRONT (N).
å
Slide the DRAWER BOTTOM (D707) into the rooves in the
DRAWER SIDES (D28 and D29) and DRAWER FRONT (N).
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
Groove
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
D28
D29
D707
D707
D28
D29
D78
D29
N
N
Unfi nished
surface
With the palm of
your hand, tap the
DRAWER BOTTOM
down into the roove.
D28
Step 26
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(12 used in this step)
30S
