å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C2 RIGHT UPRIGHT (1)
D2 LEFT UPRIGHT (1)
D53 SMALL RIGHT DRAWER SIDE (2)
D59 SMALL LEFT DRAWER SIDE (2)
D78 LARGE DRAWER BACK (3)
D109 SMALL DRAWER BACK (2)
D448 LARGE LEFT DRAWER SIDE (3)
D449 LARGE RIGHT DRAWER SIDE (3)
D707 SMALL DRAWER BOTTOM (2)
D708 LARGE DRAWER BOTTOM (3)
E BACK (2)
F2 TOP INSERT (1)
G2 MODESTY PANEL (1)
H LARGE DRAWER FRONT (3)
L SMALL DRAWER FRONT (2)
P KEYBOARD FRONT (1)
Q KEYBOARD BACK (1)
R KEYBOARD RIGHT SIDE (1)
S KEYBOARD LEFT SIDE (1)
T KEYBOARD SHELF (1)
U LONG MOLDING (2)
V SHORT MOLDING (2)
W SIDE MOLDING (4)
X BASE MOLDING (4)
Table of Contents Assembly Tools Required
2-3
4-5
6-27
28-31
32-36
37-38
39
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
402159 www.sauder.com/servicesPage 2
Part Identifi cation
Now you know
our ABCs.
Skip the power trip.
This time.
