Step 7
å
Carefully turn your unit over onto its front edges. Unfold
the BACK (E) and lay it over your unit.
å
Make equal margins along all four edges of the BACK (E).
Push on opposite corners of your unit if needed to make
it "square".
å
Fasten the BACK (E) to your unit using the NAILS (UU).
å
NOTE: Be sure to tap NAILS into the holes that line up
over the SHELF (F).
å
NOTE: A perforation has been provided for access
through the BACK. Carefully cut out the hole if needed.
å
Fasten the BALLASTS (VV and WW) to the BOTTOM (D2).
Use two BLACK 3" PAN HEAD SCREWS (84S).
411312 www.sauder.com/servicesPage 12
E
These holes must line
up over the SHELF (F).
NAIL
(52 used in this step)
UU
VV
VV
WW
WW
BLACK 3" PAN HEAD SCREW
(2 used in this step)
84S
D2
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
