Step 9
411591www.sauder.com/services
Page 13
å
Carefully stand your unit upright.
å
Before fastening the DOOR to your unit, be sure the
mounting screw is against the stops as shown in the right
diagram. If it isn't, loosen the mounting screw to slide it
against the stops. Then tighten the mounting screw.
å
Fasten the DOOR (F) to the LEFT END (B) as shown in
the lower diagram. Use the screws in the HINGES. You
should start each SCREW a few turns before completely
tightening any of them.
å
Fasten a PULL (97K) to the DOOR (F). Use two BLACK
7/8" MACHINE SCREWS (37S).
å
Repeat this step for the other DOOR (F).
å
See the next step for DOOR adjustments.
F
B
97K
BLACK 7/8" MACHINE SCREW
(4 used for the PULLS)
37S
Pro Tip: Lift with your
legs. And, you know,
your arms.
Stop
Hinge
Mounting
screw
To Next Page
