Fasten the ENDS (A and B) to the TOP (C). Tighten four
TWIST-LOCK® FASTENERS.
Step 2
411591 www.sauder.com/servicesPage 6
A
B
C
Surface with holes
How to use the SAUDER TWIST-LOCK
®
FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Dowel end
Finished edge
Edge with TWIST-LOCK® FASTENERS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
