Sauder Summit Station 425014 - Page 26

å
Carefully stand the assembly upright.
å
First, fi ll the hole in the LONG TOP (W) 1/4 to 1/2 full with
GLUE (54M). Then, insert the WOOD DOWEL (15F) into the
holes. Wipe away the excess GLUE.
å
Now, fi ll the hole in the UPRIGHT (C) 1/4 to 1/2 full with GLUE.
å
Flip the LONG TOP (W) over and fasten the TOP (W) to the
UPRIGHT (C) and SHORT MODESTY PANEL (G). Tighten six
HIDDEN CAMS.
å
NOTE: Be sure the WOOD DOWEL in the LONG TOP inserts
into the UPRIGHT. Wipe away the excess GLUE.
Step 21
425014 www.sauder.com/servicePage 26
W
G
C
Part (W). Another
sturdier, easier,
friendlier component!
Arrow
Minimum
190 degrees
Maximum
210 degrees
Fill the holes 1/4 to 1/2 full with GLUE.
Inspect the parts thoroughly before
assembling. Disassembly of glued
parts is extremely di cult.
Caution
!
F
L
I
P
O
V
E
R
54M
15F
W
54M
These holes
should be here.
