Sauder Summit Station 425014 - Page 27

å
Fasten the LONG TOP (W) to the LONG MODESTY
PANEL (E). Tighten one HIDDEN CAM.
å
Fasten the SHORT TOP (X) to the LONG TOP (W). Use
six BLACK 9/16" LARGE HEAD SCREWS (1S) through the
PLATES on the SHORT TOP and into the LONG TOP.
å
Fasten the RIGHT BACK (K) to the LEFT BACK (H). Use
three BLACK 1-15/16" FLAT HEAD SCREWS (113S).
Step 22
425014www.sauder.com/service
Page 27
W
X
H
K
Arrow
Minimum
190 degrees
Maximum
210 degrees
E
BLACK 9/16" LARGE HEAD SCREW
(6 used for the PLATES)
1S
BLACK 1-15/16" FLAT HEAD SCREW
(3 used for the BACKS)
113S
