Sauder Transit 414417 - Step 12: Attach Second Return Frame and Shelf; Fasten Second Return Frame to Bottom; Install Lower Pivot Hinge and Shelf (2 nd Frame); Install Upper Pivot Hinge and Shelf (2 nd Frame)

Step 12
å
Fasten the other RETURN FRAME (W) to the BOTTOM (K).
Use three BLACK 9/16" LARGE HEAD SCREWS (1S).
å
1st - Insert a PIVOT HINGE (15H) into the lower center hole in
the RETURN FRAME (W). Fasten the SHELF (J) to the PIVOT
HINGE in the RETURN FRAME. Use a BLACK 9/16" LARGE
HEAD SCREW (1S).
å
2nd - Then, insert a PIVOT HINGE (15H) into the upper
center hole in the RETURN FRAME (W). Fasten the SHELF (J)
to the PIVOT HINGE in the RETURN FRAME. Use a BLACK
9/16" LARGE HEAD SCREW (1S).
414417 www.sauder.com/servicesPage 16
K
J
W
15H
15H
1
st
2
nd
BLACK 9/16" LARGE HEAD SCREW
(5 used in this step)
1S
