Saurium YR-BC430 - Accelerator Assembly Details; Cutting Disc Assembly

– ACCELERATOR
1. Cogged retaining washer (1) (also equipped with a retaining hole)
2. String trimmer head.
– DISC (F4)
Lock the shaft in place by inserting the 4 mm hex key. To achieve this, it
is necessary to align the hole in the protective guard with the hole in
the shaft and insert the hex key. Align the holes by turning the
protective guard.
(1) Retaining Hole
(2) Cogged Retaining
(3) Washer
(4) Disc
(5) Washer
(6) hex Key
(7) Shaft
(F5)
Brush Cutter Head
Interior Washer
