Savannah Heating OD2000-45 - Introduction and Specifications; Appliance Specifications

Page 4 of 18
1.0 INTRODUCTION
1.1 SPECIFICATIONS
TABLE 1
ITEM
NATURAL GAS
PROPANE (LPG)
INPUT: Hi
40,500 Btu/hr (11.87 kW)
32,500 Btu/hr (9.52 kW)
INPUT: Lo
29,000 Btu/hr (8.5 kW)
24,000 Btu/hr (7.03 kW)
GAS INLET SUPPLY
PRESSURE:
Minimum: 5.0” w.c. (1.2 kPa)
Minimum: 12” w.c. (2.99 kPa)
Maximum: 13.5” w.c. (3.4 kPa)
Maximum: 14” w.c. (3.49 kPa)
AIR SHUTTER
SETTING
adjustable from 1/8” open
to fully open
Fully open
ORIFICE SIZE: @ 0-2000’
# 30 DMS
# 47 DMS
APPLIANCE DIMENSIONS
OD2000-45
43.13
47.37
43.13
14.00
16.00
25.00
31.00
