TABLE OF CONTENTS
Ch. Title Page
1 Introduction and Gallery 2
2 Recommended Skills And Tools 7
3 Specifications 8
4 Electrical Interface 12
5 Meter Compatibility 14
6 Sensus Protocol Meter Support 15
7 Neptune Protocol Meter Support 18
8 K-Frame Protocol Meter Support 21
9 Pulse Meter Support 24
10 PLC/RTU/Computer Interface 27
11 Radio Interface 29
12 Auxiliary I/O Channels 31
13 Setup and Diagnostic Utilities 35
14 MODBUS Protocol Support 50
15 DF1 and EtherNet/IP Protocol Support 57
16 ASCII Protocol Support 66
17 HTTP Web Server 68
18 Telnet Server 70
19 Network Security 71
20 References 72
21 Limited Warranty 74
22 Firmware License 76
