Modbus Register 40014 contains the 16-bit word: “Digital Status Bits”. The contents of this
word are as illustrated in the following table:
00 (Least Significant Bit)
Aux Digital I/O 1 Status (1=ON, 0=OFF)
Aux Digital I/O 2 Status (1=ON, 0=OFF)
Aux Digital I/O 3 Status (1=ON, 0=OFF)
Meter 1 Read Fault (1=Fault, 0=OK)
Meter 2 Read Fault (1=Fault, 0=OK)
Meter 1 Fwd Flow (1=Fwd Flow)
Meter 2 Fwd Flow (1=Fwd Flow)
Meter 1 Rev Flow (1=Rev Flow)
Meter 2 Rev Flow (1=Rev Flow)
15 (Most Significant Bit)
For example, if Register 40014 contains the following:
0000 1100 0000 0111 (Binary)… or 0C07 (Hexadecimal)… or 3079 (Decimal)
Then the following status conditions exist:
