Accessories
For this model you can have the following accessories:
Handle
Pull out the handle to open.
Adjustment screws
The stove has two adjustment screws on
the bottom that can be used for levelling
the stove.
Self-closing door (BA 1)
The door is prepared with a self-closing function at the fac-
tory. If you tighten the spring with the hexagon spanner, the
door will close automatically when you let go of it.
• Baking-compartment door
• Top plate in soapstone
• Shaped floor plate (steel or glass)
• Connection piece for fresh-air intake
You should read this manual as well as the General Instructions for Installation before beginning the installation.
SCAN 48
The stove can be prepared for an external air supply where
fresh air is let directly into the combustion chamber (can
also be done subsequently by the authorized dealer).
Adjustment of the air + fuel consumption (EN 13240):
Combustion air % Primary air % Max. fuel, kg Fuel consumption, kg/h
90 60 2 2
