SCAN 58 - series - ASSEMBLY

ASSEMBLY
10
Additional accessories
• Large shaped floor plate in glass or steel.
• Small shaped floor plate in steel
• Soap stone top for rear outlet
• Soap stone top for top outlet
• Soap stone top for stove with soap stone sides
• Soap stone top with hole for stove with soap stone sides
• Glass top plate for rear outlet
• Glass top plate for top outlet
• Storage door
• High top (Scan 58-7 and Scan 58-8)
• Wall mounting kit for Scan 58 with high top
Transport brackets
For Scan 58 with pedestal and see-through base / Scan 58 wall model,
remove the transport brackets as shown below.
Service box
The service box contains the following:
• Fitting for connecting piece
• Seal
• Safety fitting
• Plastic plugs for transport safety hole at the bottom of
the stove (not used for this Scan model)
• Various tools
• Glove
• Fire starters for first lighting
