SCAN 58 - series - Scan 58-9 and Scan

ASSEMBLY
19
8 distance bushings for soap stone
8 screws 6 x 30 mm for soap stone
Each soap stone is to be mounted with distance bushings and screws
(pos. H). These are delivered together with the stove. Use a Torx
screwdriver for tightening the screws. You are not to use any electri-
cal tools, as this might tighten the screws too much, resulting in the
soap stones breaking.
Mount the soap stone sides on the stove.
H
H
Scan 58-9 and Scan 58-10
Scan 58-9 and Scan 58-10 are delivered with loose soap stone plates
for mounting on the sides of the stove.
Soap stone is a natural material, wherefore there might be differen-
ces in structure and form.
The delivered gasket should be cut in pieces of 1 meter and sticked
onto the sides of the stove, on the outer side of the markings as
shown below.
Gasket
Marking
