Scantool 16A - Handle-Belt Tension

FIGURE4 PARTS LIST
Key
No.
Description
Key
No.
Description
1 knob-Motor Adjusting 23 Seat-Spring
2 Screw-Socket Set M10*1.5-12 24 Retainer-Spring
3 Handle-Belt Tension 25 Spring-Torsion
4 Pin-Stop 26 Cap-Spring
5 Ring-Depth Stop W/Scale 27 Nut-Hex M12*1.5-8
6 Lock-Depth Screw 28 Head w/Pointer and Trim
7 Hub 32 Tie-Wire
8 Guide Scale 33 Cord-Power w/Plug
9 Knob 36 Clamp-Cord
10 Rod 37 Support-Motor Bracket
11 Lock-Washer-Ext M5 38 Screw-Hex HD M6*1.0*12
12 Screw-Pan HD M5*0.8-8 39 Washer 8*16*1.6
13 Box Switch 40 Mount-Motor
14 Screw-Pan HD M5*0.8-16 41 Cord-Motor
15 Switch-Locking 42 Nut-Hex M8*1.25
16 Screw-Pan HD M4.2*1.4-8 43 Motor
18 Key-Switch 44 Nut-Hex M12*1.75
19 Cover-Switch Plate 45 Lockwasher 1/2
20 Lead-Asm 3 46 Support-Motor Bracket
21 Screw-Set Special 10*1.5-27 47 Screw-Hex HD M8*1.25-16
22 Nut-Hex M10*1.5 48 Lever-Adjusting
