SCC MPPT 3KW User Manual

18
6. SPECIFICATIONS
Table 1 Electrical Specifications
MODEL
MPPT 3KW
Nominal System Voltage
12, 24, or 48 VDC
Maximum Battery Current
60 Amps
Maximum Solar Input
Voltage
145V
PV Array MPPT Voltage
Range
60~115VDC
Maximum Input Power
12 Volt--800 Watts
24 Volt--1600 Watts
48 Volt--3200 Watts
Transient Surge Protection
4500 Watts / port
Protections
Solar high voltage disconnect
Solar high voltage reconnect
Battery high voltage disconnect
Battery high voltage reconnect
High temperature disconnect
High temperature reconnect
Table 2 Battery Charging
MODEL
MPPT 3K
Charging Algorithm
3-Step
Charging stages
Bulk, Absorption, Float
Temperature
compensation
coefficient
-5 mV / °C / cell (25 °C ref.)
Temperature
compensation range
0 °C to +50 °C
Temperature
compensated set points
Absorption, Float
